The equipment uses a high-energy, high-precision laser to drill holes in glass materials,equipped with high-definition camera positioning and professional customized operation software control system to achieve high accuracy and quality drilling effect.
Integrate multi-function into one,create more value for customer
High Precision
High Efficiency
No Damage
Various Hole Shapes
Clean Interior
No secondary processing
Optimization and innovation, make product faster, more stable and more assured.
| Item Name | Enclosed Small Format Glass Laser Drilling Machine |
| Laser Power | 80W/130W/180W |
| Laser Wavelength | 1070nm |
| Processing Depth | 0.03-2cm |
| Targeting | red light indicator |
| Processing Speed | 0-1200mm/s(adjustable) |
| Positioning Accuracy | ±0.03mm/m |
| Processing size | 400*400（standard）（adjustable） |
| Chipping | <0.1mm |
| Electricity Demand | 220V/50HZ |
| Total power protection level | IP54 |
| Cooling Method | water cooling |
|
Equipment size (length, width and height) |
105cm*100cm*140cm（adjustable） |
Widely used in various industries
Free proofing, please contact us
